Single Layer non insulation Glass
2021-05-20 838
Product number:
Hengbao single layer fire resistant glass has thicknesses of 5, 6, 8, 10, 12, 15, 19mm; the same thickness products are divided into nine series: ordinary type, SV1233, SV1333, SV2033, SV2036, SV2133, SV2136, SV3133, SV3136; The fire prevention time is 30 minutes, 60 minutes, 90 minutes, 120 minutes; the products have passed the tests of national standards GB15763.1-2009, British standard BS476 PART22 and BS EN 1364-1:1999, BS EN1634-1:2008. Synthetic hollow fireproof glass has SSV1, SSV2, SSV3 and other hollow fireproof series. (Please consult the product sales manager for details)
Ordinary glass in the fire:
1. The float glass bursts in fire for 30 seconds, and the tempered glass bursts in a fire for 1 minute.
2. The fire spreads through the gap to the surrounding exterior wall glass.
3. the surrounding exterior glass bursts to ignite indoor items.
High-strength single layer fire resistant glass for exterior walls:
1. In the event of fire in the room: high-strength single layer fire resistant glass can adhere to the temperature of 1000 °C for 30-120 minutes without bursting, effectively limiting the range of fire and smoke.
2. When a fire occurs indoors: High-strength single layer fire resistant glass is effective against fire and smoke, ensuring the safety of life and property in the room.
3. When the surrounding outer wall is a single piece of fireproof glass, it can effectively prevent the spread of fire.
Product Usage:
It is suitable for use in various natural environments. It can be processed into laminated safety fireproof glass, fireproof insulating glass, coated fireproof glass, curtain wall fireproof glass, etc. under the long-term illumination of sunlight. It is suitable for exterior wall and outdoor window. , smoke blocking vertical wall, non-insulated fireproof glass door, and fireproof partition wall curtain wall without insulation requirements.
